AxizView Camera
1 / 5
| Video | Image Sensor | 1/2.8" Progressive Scan CMOS |
| Min. Illumination | 0Lux/F1.4 (IR ON); Color: 0.02Lux, B/W: 0.002Lux | |
| Shutter | Auto/Manual (1/5~1/100000) | |
| WDR | TWDR (Off/Low/Middle/High) | |
| Day/Night | ICR switch, Auto, Color, B/W | |
| Mirror | Horizontal/Vertical/180° rotation/Corridor mode | |
| Image Settings | Brightness, Contrast, Saturation, Sharpness, Hue | |
| Intelligence | Human Detection | Support (up to 5 persons, >99% ratio) |
| VCA Analysis | Intrusion, Loitering, Line Crossing, Illegal Parking | |
| ROI | Support 4 zones | |
| Network | Compression | Smart H.265 / H.265+ / H.264 |
| Bit Rate | 16kbps~8000kbps (CBR/VBR) | |
| Protocol | TCP/IP, UDP, HTTP, DHCP, RTMP, RTSP, DDNS, Onvif | |
| Security | HTTPS encryption, AES encryption, Authorized password | |
| General | Power | PoE (802.3at) / DC 12V±10% |
| Consumption | Max 13W (IR on) | |
| Environment | -20ºC to 55ºC; 0~90% Humidity |
